- Camera
- Image Sensor 2 MP CMOS
- Signal System PAL/NTSC
- Resolution 1920 (H) × 1080 (V)
- Frame Rate
TVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
CVBS: PAL/NTSC
- Min. Illumination 0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter Time PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
- Lens 2.8 mm
- Field Of View 2.8 mm, horizontal FOV: 96.5°, vertical FOV: 48.9°, diagonal FOV: 120.5°
- Lens Mount M12
- Day & Night IR Cut Filter
- WDR (Wide Dynamic Range)Digital WDR
- Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
- Image
- Image Mode STD/HIGH-SAT
- AGC Yes
- Day/Night Mode Auto/Color/BW (Black and White)
- White Balance Auto
- AE (Auto Exposure) Mode BLC; Global; DWDR
- Noise Reduction2D DNR
- Language English
- Function Sharpness; Smart IR; Mirror; Brightness
- Interface
- Video Output Switchable TVI/AHD/CVI/CVBS
- General
- Operating Conditions -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- Power Supply 12 VDC ± 25%
- Consumption Max. 3.3 W
- Material Plastic
- IR Range Up to 20 m
- Communication HIKVISION-C
- DimensionΦ 84.6 mm × 78.9 mm (Φ 3.33″ × 3.11″)
- Approx. 195g (0.43 lb.)
