PERFORMANCE
Processor
Intel® Core™ i9-14900HX, 24C (8P + 16E) / 32T, P-core 2.2 / 5.8GHz, E-core 1.6 / 4.1GHz, 36MB
Graphics
NVIDIA® GeForce RTX™ 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 140W
Chipset
Intel® HM770 Chipset
Memory
1x 16GB SO-DIMM DDR5-5600
Memory Slots
Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory
Up to 32GB DDR5-5600 offering
Storage
1TB SSD M.2 2280 PCIe® 4.0×4 NVMe®
Storage Support
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB
Storage Slot
Two M.2 2280 PCIe® 4.0 x4 slots
Card Reader
None
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, optimized with Nahimic Audio
Camera
FHD 1080p with Privacy Shutter
Microphone
2x, Array
Battery
Integrated 80Wh
Power Adapter
300W Slim Tip (3-pin)
Special Features
AI Chip: LA1
DESIGN
Display
16″ WQXGA (2560×1600) IPS 500nits Anti-glare, 100% DCI-P3, 240Hz, DisplayHDR™ 400, Dolby® Vision®, G-SYNC®, Low Blue Light, High Gaming Performance
Touchscreen
None
Color Calibration
Factory Color Calibration
Keyboard
4-Zone RGB Backlit, Korean
Touchpad
Buttonless Mylar® surface multi-touch touchpad, 75 x 120 mm (2.95 x 4.72 inches)
Case Color
Onyx Grey
Surface Treatment
Anodizing
Case Material
Aluminium (Top), PC-ABS (Bottom)
Dimensions (WxDxH)
363.4 x 261.75 x 21.99-26.95 mm (14.31 x 10.31 x 0.87-1.06 inches)
Weight
Around 2.5 kg (5.5 lbs)
SOFTWARE
Operating System
Windows® 11 Home, Korean / English
Bundled Software
Office Trial
CONNECTIVITY
Ethernet
100/1000M (RJ-45)
WLAN + Bluetooth
Wi-Fi® 6E, 11ax 2×2 + BT5.2
Standard Ports
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
3x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with Lenovo® PD 140W and DisplayPort™ 1.4
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort™ 1.4
1x HDMI® 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Power connector
Docking
Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for Legion Pro 5 16IRX9
Security Chip
Firmware TPM 2.0 Enabled
Fingerprint Reader
None
Other Security
E-shutter
